Sepana Tork Elektrik Ringan
Sepana tork elektrik Hanpu direka untuk mengikat dan menanggalkan bolt struktur hex berat.
- Penghantaran Cepat
- Jaminan kualiti
- Perkhidmatan Pelanggan 24/7
pengenalan produk
Seperti yang kita sedia maklum, Shandong Hanpu ialah salah satu pengeluar alat elektrik terbesar di China. Produk utama yang dihasilkan ialah sepana tork elektrik, sepana ricih elektrik, sepana tork manual, sepana ricih manual, meter tork paksi, penentukur tegangan elektrik, dll.
Sepana tork elektrik Hanpu direka untuk mengikat dan menanggalkan bolt struktur hex berat.
Untuk memenuhi persekitaran pembinaan yang berbeza, kami terutamanya mempunyai dua siri yang berbeza, perbezaan terbesar ialah lengan tindak balas, siri TN- lebih biasa digunakan dalam persekitaran kerja intensif bolt, siri TL- lebih biasa digunakan dalam persekitaran kerja dengan bolt besar jarak.
Perbezaan lain ialah soket sepana, soket siri TN didedikasikan untuk Hanpu, soket siri TL adalah biasa kepada soket jenama lain dan boleh dibeli di pasaran.
Tidak kira jenis yang anda perlukan, kami akan memberikan anda harga terbaik.
Tunjukkan model sepana tork:
SIRI TN:
| Model | TN-3B | TN-5B | TN-9B | TN-7LP | TN-12LP | TN-21LP | TN-12G | TN-25G | TN-35G | |
| Kekerapan | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | |
| voltan | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | |
| Arus Maks | 6A 12A | 7A 14A | 7A 14A | 8A 16A | 8A 16A | 8A 16A | 12A 24A | 12A 24A | 12A 24A | |
| Penggunaan Kuasa Maks | 1300W | 1650W | 1650W | 1800W | 1800W | 1800W | 2800W | 2800W | 2800W | |
| Julat Tork | 100-300N.m | 200-500N.m | 400-900N.m | 350-700N.m | 500-1200N.m | 900-2100N.m | 500-1200N.m | 1000-2500N.m | 1700-3500N.m | |
| Kelajuan Ro (min-1) | 24rpm | 15.5rpm | 9.5rpm | 15rpm | 9rpm | 6rpm | 10.5rpm | 5rpm | 2.5.rpm | |
| Berat (badan utama) | 4.4KG | 4.5KG | 5.3KG | 4.7KG | 5.5KG | 6.6KG | 7KG | 8.5KG | 12KG | |
| Kelas Lindungi | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | |
| Bolts Boleh Suai Dia | S-10T | M12, M16 | M16, M20 | M20, M22, M24 | M20, M22 | M22, M24 | M27, M30 | M22, M24 | M27, M30, M33 | M30, M33, M36 |
| A325 | 1/2", 5/8" | 5/8", 3/4" | 3/4", 7/8", 1" | 3/4", 7/8" | 7/8", 1" | 1-1/8", 1-1/4" | 7/8", 1" | 1-1/8", 1-1/4",1-3/8" | 1-1/4", 1-3/8", 1-1/2" | |
| A490 | 1/2" | 5/8" | 3/4", 7/8" | 3/4" | 7/8", 1" | 1-1/8", 1-1/4" | 7/8", 1" | 1-1/8", 1-1/4" | 1-1/4", 1-3/8" | |
SIRI TL:
| Model | TL-3B | TL-5B | TL-9B | TL{0}}LP | TL{0}}LP | TL{0}}LP | TL-25G | TL-35G | TL-60G | TL-100G | |
| Kekerapan | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | |
| voltan | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | 230V 115V | |
| Arus Maks | 6A 12A | 7A 14A | 7A 14A | 8A 16A | 8A 16A | 8A 16A | 12A 24A | 12A 24A | 12A 24A | 12A 24A | |
| Penggunaan Kuasa Maks | 1300W | 1650W | 1650W | 1800W | 1800W | 1800W | 2800W | 2800W | 2800W | 2800W | |
| Julat Tork | 100-300N.m | 200-500N.m | 400-900N.m | 350-700N.m | 500-1200N.m | 900-2100N.m | 1000-2500N.m | 1700-3500N.m | 2000-6000N.m | 5000-10000N.m | |
| Kelajuan Ro (min-1) | 24rpm | 15.5rpm | 9.5rpm | 15rpm | 9rpm | 6rpm | 5rpm | 2.5rpm | 0.6rpm | 0.3rpm | |
| Berat (badan utama) | 4.4KG | 4.5KG | 5.3KG | 4.7KG | 5.5KG | 6.6KG | 9KG | 12KG | 18.5KG | 21KG | |
| Kelas Lindungi | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | Penebat Berganda | |
| Bolts Boleh Suai Dia | S-10T | M12, M16 | M16, M20 | M20, M22, M24 | M20, M22 | M22, M24 | M27, M30 | M27, M30, M33 | M30, M33, M36 | M42, M45, M48 | M48, M52, M56 |
| A325 | 1/2", 5/8" | 5/8", 3/4" | 3/4", 7/8", 1" | 3/4", 7/8" | 7/8", 1" | 1-1/8", 1-1/4" | 1-1/8'', 1-1/4", 1-3/8", | 1-1/4", 1-3/8", 1-1/2" | 1-5/8", 1-3/8", 2" | 2", 2-1/8", 2-1/4" | |
| A490 | 1/2" | 5/8" | 3/4", 7/8" | 3/4" | 7/8", 1" | 1-1/8", 1-1/4" | 1-1/8'', 1-1/4" | 1-1/4", 1-3/8" | 1-5/8", 1-3/8" | 2", 2-1/8" | |
Jika anda berminat dengan mana-mana sepana tork model, sila hubungi kami!
Email: marketing@hanputool.com Phone: plus 86 18653495537
